Laminated Film Inspection

EasyInspect for laminated film inspection offers reliable in-line inspection solutions that detect defects and irregularities in laminated film material.

EasyMeasure monitors 100 % of the large area material properties, such as haze, thickness and many more.

EasyInspect for laminated film inspection is used for local defect detection, e.g. for:

  • Coating void defect detection
  • Wrinkle defect detection
  • Contamination defect detection
  • Gluing defect detection
PCB material inspection

The Dr. Schenk inspection solutions provide complete process control and defect classification. This helps manufacturers to gain maximum yield and deliver quality produce. The inspection of local defects and the measurement of lamination properties, such as layer thickness and homogeneity, are performed at production speed without any delays. Real-time feedback into the production line helps to achieve process optimization quickly and reliably.

EasyInspect & EasyMeasure for laminated film inspection use Dr. Schenk’s unique MIDA Technology so all kinds of laminated film defects can be fully analyzed in one inspection run. Thanks to ultra-high speed illumination multiplexing and multiple optical channels per camera line all issues can be detected and classified with more information per defect, at higher production speed, than any other inspection technology can offer.

Coating void defect
Contamination defect
Gluing defect
Wrinkle defect
Local defect detection
Property monitoring
